产品概述

lec-2281是另一款高性能盒式pc lec-2280的延续版和升级版。无风扇的lec -2281配备英特尔®第四代core™i7/i5/i3处理器，提供更丰富的扩展和i/o选项，包括英特尔®hd graphics 4600, hdmi, vga和dvi-d接口，双2.5" hdd/ssd驱动器托架和一个msata插槽;扩展可以通过pci, pci express x16和带sim卡读卡器的全尺寸mini-pcie插槽实现。lec-2281的高性能处理器、可伸缩扩展能力和灵活的i/o选项使其成为几乎所有物联网和工业4.0应用场景的一体化、一机多用yb体育app官方下载的解决方案。

产品规格

platform
cpu	intel® core™ i7-4700eq/i5-4400e/ i3-4102e
chipset	intel® qm272
bios	ami 128mbit spi flash bios
memory technology	ddr3l 1333/1600mhz
memory capacity	16 gb
memory socket	2x 204-pin sodimm
storage
sata storage	2x 2.5” hdd/ssd drive bay
i/o
ethernet controller	intel® i217lm and i210at
graphic controller	intel® hd graphics 4600
audio controller	realtek alc886
default lan	2 x rj45
display output	1x vga, 1920 x 1080,1x dvi-d, 1920 x 1200,1x hdmi, 3840 x 2160 @24hz or 2560 x 1600 @60hz
audio ports	2x phone jack for mic-in and line-out
serial ports	2x rs-232/422/485, db9 male
usb 2.0	4 x type a
usb 3.0	2 x type a
expansion	1x full-sized socket with sim card reader/1x full-sized socket
reset	1x power on/off, 1x reset
os and certifications
operating system	wes 7 e, win 7 pro fes, we 8.1 industry pro, kernel 3.x
certifications	ce/fcc, class a
physical and environmental
storage temperature	-20°c to 70°c
operating temperature	-10°c to 45°c
operating humidity	5% to 95% (non-condensing)
dimensions (w x h x d)	277 mm x 78 mm x 195 mm (10.91" x 3.07" x 7.68")
weight	3.8 kg (8.36 lbs)
casing material	aluminum sgcc

订购信息

lec-2281-711a

无风扇工业pc，英特尔®酷睿™i7-4700eq cpu



all product specifications are subject to change without prior notice
