产品概述

lec-2430是一款具有成本效益、节能和功能强大的嵌入式设备。其无风扇、坚固和紧凑的设计简化了有限空间的部署和维护。其英特尔®赛扬®j1900/n2930或英特尔®atom™e3845处理器提供了大大提高的图形/媒体性能，而其mini-pcie, pci和pci- e riser卡提供扩展能力和扩展功能。

产品规格

platform
cpu	intel celeron j1900 processor
chipset	2 ghz
bios	ami spi flash bios
memory technology	ddr3l, 1333 mhz
memory capacity	8gb
memory socket	1 x 204-pin sodimm
storage
sata storage	1 x 2.5” hdd/ssd drive bay
i/o
ethernet controller	intel i210
graphic controller	intel hd graphics
audio controller	realtek alc886
max lan	2 x rj45
display output	1 x vga, 1600 x 1200, 1 x hdmi, 1920 x 1080
audio ports	2 x phone jack for mic-in and line-out
serial ports	2 x rs-232/422/485, db9 male
usb 2.0	4 x type a
usb 3.0	1 x type a
expansion	1 x full-sized socket with sim card reader,1 (default) pci, 1 (accessorary package) pci express x1
reset	1 x power on/off, and 1 x reset
os and certifications
operating system	win7, wes7, win8.1, kernal 3.12
certifications	ce/fcc, class a
physical and environmental
storage temperature	-20°c to 70°c
operating temperature	0°c to 55°c
operating humidity	5% to 95% (non-condensing)
dimensions (w x h x d)	268 mm x 65.5 mm x 195 mm (10.55" x 2.58" x 7.68")
weight	2.7 kg (5.94 lbs)
watchdog	watchdog timer 256 level time interval system reset, software programmable
casing material	aluminum sgcc

订购信息

lec-2430-j11a

无风扇机箱pc，英特尔赛扬处理器j1900 @2ghz cpu



all product specifications are subject to change without prior notice
