特点&外观
- intel® atom™ cpu
- 5x rj45, 2x usb
- 2x com
iec 61850-3宽温ics网络安全网关
- wide temperature ics cyber security box pc
- iec 61850-3 and ieee 1613 certified
- intel® atom™ x7-e3950 or x5-e3930 cpu
- 5 x gbe lan with 1 pair bypass, 2 x gbe sfp
- onboard tpm support
- hdmi display output
- mini-pcie with sim card slot for 4g-lte support
- 2 x usb 3.0 and 2 x isolated rs232
产品概述
lec-6041是lec-6021的延续版，旨在保护it和ot领域的通信。lec-6041系列采用intel atom x7-e3950或x5-e3930处理器，具有低功耗和高性能。作为一种坚固型防火墙，通常部署在具有挑战性的环境中，具有iec 61850-3和ieee 1613认证，以及lan端口的1.5 kv磁隔离保护和i/o端口的15kv esd保护。该系统可以在-40°c到70°c的工作温度范围内工作。所有的硬件设计保证了安全网关lc -6041在危险环境(如ot环境)中运行时永远不会停机。
产品规格
| platform | |
| cpu | intel atom x7-e3950 or x5-e3930 |
| chipset | soc |
| bios | ami spi flash bios |
| memory technology | ddr3l, 1866 mhz |
| memory capacity | 8 gb |
| memory socket | 1 x 204-pin sodimm |
| storage | |
| sata storage | 1 x sata connector with 2.5” drive bay (optional) |
| i/o | |
| ethernet controller | intel i210 |
| graphic controller | intel hd 505 graphics |
| default lan | 5 x rj45 2 x sfp |
| bypass | 1 pair bypass |
| magnetic isolation protection | 1.5 kv built-in |
| serial ports | 2 x rs-232, db9 male |
| usb 3.0 | 2 x type a |
| power and mechanical | |
| power input | phoenix contact 6-pin connector with lock |
| expansion | 1x mini-pcie with 1 sim card for 4g lte module (usb & pcie signal) |
| reset | internal reset button |
| os and certifications | |
| operating system | windows 10 pro, linux kernel 4.x |
| compliance | ce, fcc class a, iec 61850-3 compliance |
| physical and environmental | |
| storage temperature | -40°c to 85°c |
| operating temperature | -40°c to 70°c |
| operating humidity | 5% to 95% (non-condensing) |
| dimensions (w x h x d) | 160 mm x 166 mm x 53.5 mm (6.30" x 6.54" x 2.11") |
| weight | 1.6 kg (3.52 lbs) |
| watchdog | watchdog timer 256 level time interval system reset, software programmable |
| casing material | aluminum sgcc |
订购信息
| lec-6041a | iec 61850-3 wide temperature ics cyber security gateway with intel atom x5-e3930 processor |
| lec-6041b | iec 61850-3 wide temperature ics cyber security gateway with intel atom x7-e3950 processor |
all product specifications are subject to change without prior notice
