特点&外观
- intel® celeron® n2807
- 3x rj45, 3x usb
- 2x mini-pcie
基于intel®celeron®n2807 soc和丰富i/o的sff mes精简型客户端网关
- intel® celeron® n2807 cpu
- intel® hd graphics
- 3x gbe ethernet ports, 1x usb3.0 and 2x usb2.0 ports
- 1x hdmi with 1920 x 1080 resolution
- 1x msata, 2x rs-232/485 serial ports
- 4x di and 4x do
- 1x full-sized mini-pcie slot with sim slot for 3g/lte communication
- 1x half-sized mini-pcie slot for wireless communication
产品概述
lec-7233是一个精简型客户端网关，由双核intel®赛龙®n2807 soc(编号为bay trail)供电。使其成为制造执行系统(mes)理想的多业务通信网关。
产品规格
| platform | |
| cpu | intel® celeron® n2807 |
| bios | ami spi flash bios, 64mbit |
| memory technology | ddr3l 1333mhz |
| memory capacity | 4 gb |
| memory socket | 1x 204-pin sodimm |
| storage | |
| sata storage | 1x msata socket |
| i/o | |
| ethernet controller | intel® i211 |
| graphic controller | intel® hd graphics |
| default lan | 3x rj45 |
| serial ports | 2x rs-232/485, d-sub9 male |
| digital i/o | 4x di, 4x do |
| usb 2.0 | 2 x type a |
| usb 3.0 | 1 x type a |
| power input | 12vdc |
| type/watt | atx |
| expansion | 1x full-sized socket with sim card reader and 1x half-sized socket |
| reset | 1x power on/off, 1x reset |
| os and certifications | |
| operating system | wes7e, win7 pro fes, we 8.1 industry pro, win 10 iot, kernal 3.12 |
| certifications | ce/fcc, class a |
| physical and environmental | |
| vibration | iec 60068-3-64, 0.5grms, random 5~500 hz, 40 mins/axis |
| storage temperature | -20°c to 70°c |
| operating temperature | 0°c to 50°c |
| operating humidity | 5% to 95% (non-condensing) |
| dimensions (w x h x d) | 164.5 mm x 30 mm x 143 mm (6.48" x 1.18" x 5.63") |
| weight | 0.9 kg (1.98 lbs) |
| watchdog | watchdog timer 1~255 level time interval system reset, software programmable |
| casing material | sgcc |
订购信息
| lec-7233-c11a | fanless industrial pc with intel® celeron® n2807cpu |
all product specifications are subject to change without prior notice
