特点&外观
- intel® apollo lake
- 2x rj45, 2x usb
- 1x mini-pcie
new
具有intel®apollo lake cpu和fcc/ce/ptcrb lte或wifi认证的工业无线网关
- intel® apollo lake cpu
- 2x gbe rj45, 1x rs232/422/485 com port
- 2x usb 3.0, 1x display port, 1x hdmi
- 1x m.2 3042 b m key socket w/ dual sim
- 1x mini-pcie socket w/ dual sim
- onboard lpddr4, max 8gb & onboard 64gb emmc
- tpm support
产品概述
lec-7242是一个工业环境网关ipc与英特尔®apollo lake cpu。该无线网关具有fcc/ce/ptcrb认证，适用于lte或wifi，适用于商业、企业和公共部门应用的物联网/iiot边缘、无线安全和多站点管理yb体育app官方下载的解决方案部署。
产品规格
| processor system | |
| cpu | intel® apollo lake: celeron® n3350 / atom® x5-e3940 |
| frequency | 2.4ghz / 1.8ghz |
| core number | 2 / 4 |
| bios | ami spi flash bios, 16mbit |
| fanless | |
| yes | |
| memory | |
| technology | onboard non-ecc lpddr4 2400 |
| max. capacity | 8 gb (default 4 gb) |
| socket | - |
| graphic | |
| controller | intel® hd graphics 500 |
| display | 1x hdmi, 1x display port |
| ethernet | |
| controller | intel® i210-at / intel® i210-it |
| speed | 10/100/1000 mbps |
| interface | 2x rj45 |
| storage | |
| type | emmc & sata (design reserved) |
| installation | onboard 64gb emmc 1x sata (design reserved) |
| i/o | |
| serial port | 1x rs-232/422/485, db9 male |
| digital i/o | - |
| usb 2.0 | - |
| usb 3.0 | 2x type a |
| power-on/reset button | 1x power on/off, 1x reset |
| led | yes |
| antenna hole | 4x sma antenna holes |
| expansion interface | |
| m.2 | 1x m.2 3042 b m key socket w/ dual sim for lte or wifi |
| mini-pcie | 1x mini pcie socket w/ dual sim for lte |
| watchdog timer | |
| watchdog timer 1~255 level time interval system reset, software programmable | |
| power | |
| power type | atx |
| power supply voltage | 12vdc |
| connector | dc jack with lock |
| power consumption (idle) | 6.3w |
| power consumption (full load) | 9.5w |
| environment | |
| operating temperature | 0°c~50°c / -20°c~70°c |
| storage temperature | -30°c~70°c |
| relative humidity | 5%~95% (non-condensing) |
| vibration | - |
| mechanical | |
| dimension (w x h x d) | 168 x 40 x 145 mm |
| construction | aluminum extrusion with sgcc |
| weight | tbd |
| mounting | wallmount |
| driver support | |
| microsoft windows | wes7e, win7 pro fes, we 8.1 industry pro, win 10 iot |
| linux | kernal 3.12 |
| certification | |
| emc | ce/fcc class a, ul |
| safety | - |
订购信息
| lec-7242a | commercial grade (op temp 0~50), intel celeron n3350, 4gb lpddr4 memory, intel i210at ethernet, mini-pcie for lte & m.2 for lte, w/ ac/dc adapter |
| lec-7242b | commercial grade (op temp 0~50), intel celeron n3350, 4gb lpddr4 memory, intel i210at ethernet, mini-pcie for lte & m.2 for wifi, w/ ac/dc adapter |
| lec-7242c | industrial grade (op temp -20~70), intel atom x5-e3940, 4gb lpddr4 memory, intel i210it ethernet, mini-pcie for lte & m.2 for lte, w/ ac/dc adapter |
| lec-7242d | industrial grade (op temp -20~70), intel atom x5-e3940, 4gb lpddr4 memory, intel i210it ethernet, mini-pcie for lte & m.2 for wifi, w/ ac/dc adapter |
all product specifications are subject to change without prior notice
