特点&外观
- intel celeron n2930
- 2x rj45, 3x usb
- 1x mini-pcie
英特尔®bay trail无风扇监控平台
- intel® celeron® j1900/n2930 or atom™ e3845
- vga (1600x1200) & hdmi (1920x1080) video-out
- fanless & power-conscious
- dual gbe ports
- dual serial com ports
- high-speed usb 3.0
- integrated sim card reader
- j1900/n2930: 0°c~55°c ; e3845: -20°c~55°c
产品概述
lec-7331作为紧凑、轻量型平台，采用intel®赛扬®j1900/n2930或intel®atom™e3845处理器，提供四核处理和一个2.5"或3.5" hdd/ssd硬盘槽位，便于视频管理，使其成为一个快速而低维护的平台，用于设置视频密集型工业部署，如物理安全、路边交通监控和其他监控或its相关工业应用。
产品规格
| platform | |
| cpu | intel® celeron® j1900/n2930 or atom™ e3845 |
| chipset | soc |
| bios | ami 32mbit spi flash bios |
| memory technology | ddr3l 1333mhz |
| memory capacity | 8 gb |
| memory socket | 1x 204-pin sodimm |
| storage | |
| sata storage | 1x 2.5” or 3.5” hdd/ssd drive bay |
| i/o | |
| serial ports | 2x rs-232/422/485, db9 male |
| usb 2.0 | 2 x type a |
| usb 3.0 | 1 x type a |
| power and mechanical | |
| power input | 12 vdc |
| expansion | 1 x full-sized socket with sim card reader |
| reset | 1x power on/off, 1x reset |
| os and certifications | |
| operating system | win7e, wes7, win8.s, kernal 3.12 |
| certifications | ce/fcc, class a |
| physical and environmental | |
| vibration | iec 60068-2-64, 0.5grms, random 5 ~500 hz, 40 mins/axis |
| storage temperature | -20°c to 70°c |
| operating temperature | 0 or -20°c to 55°c |
| operating humidity | 5% to 95% (non-condensing) |
| dimensions (w x h x d) | 200 mm x 70.4 mm x 143.8 mm (7.87" x 2.77" x 5.66") |
| weight | 1.3 kg (2.86 lbs) |
| watchdog | watchdog timer 1~255 level time interval system reset, software programmable |
| casing material | aluminum |
订购信息
| lec-7331-j11a | fanless industrial pc with intel® celeron® j1900 (2 ghz) cpu |
| lec-7331-n11a | fanless industrial pc with intel® celeron® n2930 (1.83 ghz) cpu |
| lec-7331-e51a | fanless industrial pc with intel® atom™ e3845 (1.91 ghz) cpu |
all product specifications are subject to change without prior notice
