特点&外观
- intel atom e3845
- 2x rj45, 2x usb
- 3 mini-pcie
英特尔atom e3825或e3845无风扇车辆网关控制器
- power-efficient intel® atom™ e3825 or e3845 cpu
- 1 x ddr3l sodimm up to 4 gb memory
- 2 x intel® 10/100/1000 mbps rj-45 ports
- 3 x mini-pcie sockets with total 4 external accessible sim card reader, supporting wi-fi/3g/4g/lte
- compliant with mil-std-810g vibration/shock resistance
- onboard gps receiver module and g-sensor
- 1 x msata,1 x sata 2.0 for 2.5" hdd storage
- wide range operating temperature from -20 to 60°c
- 1 x usb 3.0 port and 1 x usb 2.0 port
- optional can bus port
产品概述
lvc-2001是一款无风扇车辆系统，具有节能型cpu、丰富的i/o功能和环保耐力，适用于移动车辆设置。该设备配备新一代soc (system-on-chip) intel®bay trail atom™e3825或e3845 cpu。该处理器耗电量低，可满足车辆计算需求。
lvc-2001还提供可扩展功能，拥有丰富的i/o外设连接，包括2个串口，2个视频输出hdmi和vga, usb和数字i/o端口，2个rj-45 lan端口和sata/msata存储选项。为了实现无线网络连接，lvc-2001提供3个mini pcie插槽，4个sim卡读卡器，支持3g/4g/lte蜂窝通信。此外，紧凑型系统还提供了一个can总线选项，以解决驾驶行为分析的问题。
产品规格
| platform | |
| cpu | intel® atom soc e3825 or e3845 cpu |
| chipset | n/a (soc) |
| bios | ami spi flash bios |
| memory technology | ddr3l sodimm |
| memory capacity | max up to 4 gb |
| storage | |
| sata storage | 1 x internal 2.5” 9.5 mm drive bay |
| i/o | |
| ethernet controller | 2 x intel® i210-it |
| graphic controller | intel hd graphics |
| max lan | 2 x rj45 lan ports |
| display output | 1 x vga, 1 x hdmi |
| serial ports | com1/com2: 2 x rs-232/422/485 with ri/5v/12v |
| usb 2.0 | 1 x type a |
| usb 3.0 | 1 x type a |
| expansion | 2x full-size mini-pcie socket (1x usb pcie 2x sim; 1x usb 2 x sim ) 1x half-size mini-pcie socket |
| hardware monitor | fintek f81865 integrated watchdog timer 1~255 level |
| os and certifications | |
| operating system | windows: wes7 (ws7e) /w7 pro sp1 / we8 std /win 10 iot,linux: redhat enterprise 5 |
| certifications | ce/fcc class a, e13, rohs |
| physical and environmental | |
| storage temperature | -20°c to 60°c |
| operating temperature | -5°c to 45°c |
| storage humidity | 5% to 95% (non-condensing) |
| dimensions (w x h x d) | 198 mm x 52 mm x 185 mm (7.80" x 2.05" x 7.28") |
| weight | 1.8 kg (3.96 lbs) |
| casing material | heavy steel |
订购信息
| lvc-2001-a1 | intel® atom soc e3845 cpu in-vehicle computer, 1 x ddr3l sodimm, mini-pcie x3, usb 3.0 host x 1, usb 2.0 host x1, serial port x2, optional can bus x1, dc power input 9~36vdc with ignition |
| lvc-2001-a2 | intel® atom soc e3825 cpu in-vehicle computer, 1 x ddr3l sodimm, mini-pcie x3, usb 3.0 host x 1, usb 2.0 host x1, serial port x2, optional can bus x1, dc power input 9~36vdc with ignition |
all product specifications are subject to change without prior notice
