特点&外观
- intel atom n4200
- 10x rj45, 2x usb
- 4x di/o
intel®atom®n4200/x7-e3950 用于视频监控与计算机视觉
- intel® atom® n4200/x7-e3950
- lpddr4 sdram (max. 4gb), emmc (max. 64gb)
- 2x 100/1000 mbps lan, 8x poe , 2x usb3.0, 4x di&do
- 1x 3.5” hdd bay, 2x onboard sata ports
- 2x system fans, 54 vdc power input
产品概述
nva-3000采用intel®atom®n4200/x7-e3950 cpu, 拥有8个poe接口，2个rj45 lan接口，4gb pddr4内存，intel®hd显卡，1u外形。它是视频和图形密集型应用的理想yb体育app官方下载的解决方案，通常在视频监控/机器视觉和/或工业自动化中使用。
产品规格
| platform | |
| cpu | intel® atom® n4200/x7-e3950 |
| chipset | soc |
| bios | ami 32mbit spi flash bios |
| memory technology | lpddr4 2400mhz |
| memory capacity | 4 gb |
| memory socket | onboard |
| storage | |
| sata storage | 1x 3.5” hdd/ssd drive bay |
| i/o | |
| ethernet controller | intel® i210it, i210is, marvell 88e6390 ethernet switch, 88e1512 phy |
| graphic controller | intel® hd graphics |
| default lan | 2x rj45 8x rj45 poe |
| digital i/o | 4x di, 8x do with 5v ttl |
| usb 3.0 | 2 x type a |
| power and mechanical | |
| power input | atx 54 vdc |
| reset | 1x reset button |
| os and certifications | |
| operating system | wes7, win 7 pro fes, we 8.1 industry pro, win 10 iot, kernal 3.12 |
| certifications | ce/fcc, class b |
| physical and environmental | |
| vibration | iec 60068-2-64, 0.5grms, random 5 ~500 hz, 40 mins/axis |
| storage temperature | -20°c to 60°c |
| operating temperature | 0°c to 40°c |
| dimensions (w x h x d) | 310 mm x 44 mm x 220 mm (12.20" x 1.73" x 8.66") |
| watchdog | watchdog timer 1~255 level time interval system reset, software programmable |
| casing material | sgcc |
订购信息
| nva-3000a | intel apollo lake n4200 1.10ghz cpu emmc 8gb |
| nva-3000b | intel apollo lake x7-e3950 1.6ghz cpu emmc 64gb |
all product specifications are subject to change without prior notice
