特点&外观
- intel® core™ i7-7600u
- 10x poe, 4x usb, 2x com
- 1x mini-pcie
new
intel®core™i7-7600u无风扇车载nvr
- intel® core™ i7-7600u dual cores processor
- mil-std-810g and e-mark certified
- 10x poe (supports 5x poe ) and 1x gbe rj45 ports
- 2 x swappable 2.5” hdd drive bays
- 1 x full-sized mini-pcie with dual sim card reader for lte/ wi-fi, and 1x external m.2 3042 with sim
- 2x com, 2x usb 2.0, 2x usb 3.0, 6x di/do, optional can bus, audio, dvi, vga
- built in wall mount kit
- fanless rugged design
产品概述
v6s是下一代坚固型、无风扇车辆监控nvr。专为公共交通视频监控、记录和分析而设计的。v6s可在较宽的温度范围(-20~60℃)下工作，在恶劣环境下也具有良好的可靠性。
v6s由第七代14纳米intel®酷睿™i7-7600u soc(formerly kaby lake)提供动力，为车辆计算需求提供高效节能性能和加速图形性能。
全新的v6s系列专为移动监控设计，提供1 × gbe rj45接口和10 × rj-45 poe接口，用于ip摄像头连接，拥有两个可拆卸的2.5”hdd/ssd驱动器槽，用于存储录制视频。对于无线连接，v6s内部内置1个带双sim卡读卡器的全尺寸mini-pcie, 1个用于wifi的全尺寸mini-pcie，以及1个外接带双sim卡读卡器的mini-pcie 3.0，可拆卸4g/lte模块。
产品规格
| platform | ||
| cpu | intel® core™ i7-7600u (kaby lake) | |
| chipset | soc | |
| bios | ami spi flash bios | |
| memory technology | ddr4 2133 so-dimm socket x2 | |
| memory capacity | up to 32gb, pre-installed 8gb | |
| storage | ||
| sata storage | 2x removable 2.5” drive bays (hdd/ssd is not included) | |
| i/o | ||
| ethernet controller | 11x rj45 with 3x intel i210it | |
| poe | 5x ieee802.3at poe 5x ieee802.3af poe ports | |
| display output | dvi-d/vga | |
| audio ports | 1x db9 for mic-in and line-out | |
| digital i/o | 6x di 5v or 12v ttl selectable 6x do 12v ttl, max. 100ma 2x ign-di of ignition control to mcu | |
| usb 2.0 | 2 x type a | |
| usb 3.0 | 2 x type a | |
| power and mechanical | ||
| power input | dc 9~36v ( , - , ignition) supports atx mode support ignition delay on/ off control | |
| expansion |
|
|
| processor cooling | passive cpu heatsink | |
| system cooling | fanless design with corrugated aluminum | |
| os and certifications | ||
| operating system | win10 iot, redhat enterprise 5, fedora 14. linux kernel 2.6.18 or later | |
| certifications | ce class a, fcc class a, rohs, e-13 include iso-7637-2 | |
| physical and environmental | ||
| storage temperature | -20°c to 70°c | |
| operating temperature | -20°c to 60°c | |
| operating humidity | 5% to 95% (non-condensing) | |
| dimensions (w x h x d) | 307 x 188 x 105.2 mm (v6s) 223 x 143.8 x 45.7 mm (lvp-936bat01) |
|
| weight | 5.5 kg (12.1 lbs) | |
| internal rtc | yes | |
订购信息
| v6sa | intel® core i7-7600u in-vehicle mobile nvr with 10x intel gbe poe and iv-vpb6sa1a, external 200w dc power adapter for 9v~36vdc input with ignition |
all product specifications are subject to change without prior notice
