电信应用运算平台
- intel atom denverton
- wide temp.-40~70ºc
- 4x rj45, 2x sfp
new
宽温网络设备intel®atom®c3000 (denverton)
- intel® atom® 2~8 cores c3308/c3508/c3708 cpu (denverton)
- 4x rj45, 2x sfp or 2x rj45 (by sku), 1 pair of gen3 bypass
- wide operating temperature range: -40~70ºc (sku c to 60ºc)
- sku a/d:1x 260-pin sodimm, sku b/c/e/f:2x 260-pin sodimm
- 1x m.2 b key 3042 for lte, 2242 ssd (signal: usb3.0, sata) with nano-sim
- 2x mini-pcie for wi-fi,lte (signal: usb2.0,pcie) with nano-sim
- sku d/e/f: 1x optional removable m.2 lte caddy
- intel® quickassist technology up to 10gbps
- 1x mini usb console, 2x usb 3.0 (sku b/c), 1x 2.5” hdd/ssd bay (optional)
- optional rack mounting kit support
电信应用运算平台
- 8th intel core coffee lake
- 4x ddr4 128gb max
- 8x lan max, 2x nic
1u 19 "机架式网络设备，内置intel® xeon® e or core i3 or pentium or celeron 处理器(代号coffee lake)
- intel® xeon® e or core i3 or pentium or celeron processor (codenamed coffee lake)
- 8x gbe rj45 (sku a), 4x gbe rj45 or 4x gbe sfp ports (by project), 2x nic module slots, max. 5 pairs of lan bypass
- ddr4 2666mhz ecc (by cpu) or non-ecc udimm, max.128gb
- 2x mgmt, 1x console, 1x lom via ipmi card (optional), 2x usb 3.0, 4x keypads
- 2x 2.5” hdd/ssd bays, 1x m.2 2242, b m key (optional)
- 2x pci-e*4 fh/hl (optional), 2x system fans, 300w 1 1 atx redundant psus
电信应用运算平台
- intel denverton c3336 2核
- 1 x ddr4 ecc/non-ecc
- 4 x gbe rj45 2 x combo
助力企业快速上云yb体育app官方下载的解决方案
- 板载intel denverton c3336/c3558 2 cores/4 cores processor
- 1个ddr4 ecc/non-ecc sodimm 内存,max 16g
- 板载16g emmc,1个ata3.0
- 板载3个m.2接口可以支持5g、lte和wifi等功能扩展
- 板载4 x gbe rj45 2 x combo lan ports
- 支持intel quick assist 功能，支持ipsec/ssl vpn，支持aes等通用加密算法
电信应用运算平台
- intel atom denverton
- 4x rj45, 2x sfp & 2x rj45
- lte, 5g & wifi ready
new
桌面网络一体机的vcpe/ucpe和边缘安全
- intel® atom® c3000 processor (codenamed denverton)
- max. 4x rj45, 2x sfp & 2x rj45 (by sku)
- 2x 260-pin ddr4 2400/2133/1866mhz ecc/non-ecc sodimm (by sku), max. 32gb
- design ready for 5g sub-6 and wifi 6 (802.11ax)
- 1x rj45 console, 2x usb 2.0, 1x rj45 lom
- 2x mini-pcie, 1x m.2 2242 b key, 2x nano sim for m.2
- mpcie expansion slot for edge ai accelerator (intel movidius)
- 1 x 2.5” drive bay (optional)
- support tpm 2.0
- 1 x cooling fan w/ smart fan (sku a~e) or 2 x cooling fans w/ smart fan (sku f)
电信应用运算平台
- intel® xeon d2700/d2800
- 10g sfp , 25g sfp28
- -40~65ºc temp. range
高性能边缘计算设备，配备intel至强®d-2800系列多核处理器(代号eddy lake d)
- intel®xeon®d2700/2800 8~22核
- 4x ddr4 3200/2933mhz reg rdimm，最大256gb
- 8个10g sfp ， 2个25g sfp28, 2个gbe rj45, 2个usb 3.0
- 1个rj45控制台，2个2280 m.2(1个nvme和1个sata)
- -40c~65c工作温度(sku b/c/e)
- 1个ocp 3.0, 1个pcie*16
电信应用运算平台
- intel®xeon d-2100
- 短深度机箱
- 宽温
短深度机箱边缘计算设备，配备intel至强®d-2100多核处理器(代号skylake-de)
- intel®至强d-2100 12/16核处理器
- 宽温-40~65℃
- 2个ddr4 2667 mhz reg, ecc rdimm，最大64gb
- 前端接入i/o: 1个gbe rj45 ipmi, 8个10g sfp ， 2个40g qsfp ， 1个rj45 console, 1个usb 3.0和前置风扇更换
- 2个2.5 "内部硬盘/固态硬盘槽，2个m.2 nvme 2280m密钥
- 1个pci-e*16 fh/hl插槽，可用于fpga或gpu卡
- 可选g.8272 t-gm兼容ieee 1588v2 syne，机载gps
电信应用运算平台
- intel® xeon d-2100
- short depth chassis
- wide temperature
1u 19英寸机架安装开放式ran设备，配备英特尔至强d-2100多核处理器（代号skylake de）
- intel® xeon d-2100 8/12/14/16 核处理器
- 短深度底盘，宽温-40~65ºc
- 2x ddr4 2667 mhz reg, ecc rdimm, max. 64gb
- 带1x gbe rj45的前端接入i/o，用于ipmi、8x 10g sfp 、1x rj45控制台、1x usb 3.0和无螺丝风扇更换
- 4x 2.5” internal hdd/ssd bays, 1x m.2 nvme 2280 m key
- 1个pci-e x16插槽，用于fpga或gpu卡
- intel®quickassist技术
