特点&外观
- intel atom denverton
- 4x rj45, 2x sfp & 2x rj45
- lte, 5g & wifi ready
new
桌面网络一体机的vcpe/ucpe和边缘安全
- intel® atom® c3000 processor (codenamed denverton)
- max. 4x rj45, 2x sfp & 2x rj45 (by sku)
- 2x 260-pin ddr4 2400/2133/1866mhz ecc/non-ecc sodimm (by sku), max. 32gb
- design ready for 5g sub-6 and wifi 6 (802.11ax)
- 1x rj45 console, 2x usb 2.0, 1x rj45 lom
- 2x mini-pcie, 1x m.2 2242 b key, 2x nano sim for m.2
- mpcie expansion slot for edge ai accelerator (intel movidius)
- 1 x 2.5” drive bay (optional)
- support tpm 2.0
- 1 x cooling fan w/ smart fan (sku a~e) or 2 x cooling fans w/ smart fan (sku f)
产品概述
nca-1515是一款由英特尔®atom®c3000(代号denverton) cpu驱动的桌面网络设备，具有强大的性能和英特尔的quickassist技术，可提供加密加速和商业级lan功能；该平台提供了一个m.2扩展插槽，支持intel movidius myriad x视觉处理单元(vpu)。intel movidius vpu为开发人员创建了一个可靠的硬件平台，用于部署用于智能监控、流量管理、访问控制、零售等领域的健壮的edge aiyb体育app官方下载的解决方案。
产品规格
| platform | |
| cpu | intel® atom® c3000 (denverton) |
| chipset | soc |
| bios | ami spi flash bios |
| memory technology | ddr4 2400/2133/1866mhz ecc dimm |
| memory capacity | 32gb |
| memory socket | 2 x 260-pin sodimm |
| storage | |
| sata storage | 1 x emmc 8gb |
| i/o | |
| default lan | max. 4x rj45, 2x sfp & 2x rj45 |
| console | 1 x rj45 |
| security acceleration | intel® quickassist technology |
| usb 2.0 | 2 x type a |
| tpm | tpm 2.0 |
| power and mechanical | |
| power input | 1 x dc jack |
| type/watt | 36w or 60w power adapter (by sku) |
| expansion | 2 x mini-pcie (pcie/usb2.0), 1 x m.2 2242 b key (usb3.0), 2 x nano sim for m.2 |
| reset | 1 |
| processor cooling | passive cpu heatsink |
| system cooling | 1 x cooling fan w/ smart fan (sku a~e) ; 2 x cooling fans w/ smart fan (sku f) |
| os and certifications | |
| certifications | sku a~e: rohs, ce/fcc class b, ul, vcci, rcm, ccc ; sku f (by project): compliance pendng |
| physical and environmental | |
| storage temperature | -20°c to 70°c |
| operating temperature | 0°c to 40°c |
| operating humidity | 5% to 95% (non-condensing) |
| dimensions (w x h x d) | 231 mm x 44 mm x 200 mm (9.09" x 1.73" x 7.87") |
| weight | 1.2 kg (2.64 lbs) |
| watchdog | yes |
| internal rtc | yes |
订购信息
| nca-1515a | c3758, 8-core, 2x ddr4 ecc sodimm, 4x gbe rj45 w/ 1 pair of gen3 bypass, 2x gbe sfp w/ led & 2x gbe rj45, w/bmc, 60w adapter |
| nca-1515b | c3558, 4-core, 2x ddr4 ecc sodimm, 4x gbe rj45 w/ 1 pair of gen3 bypass, 2x gbe sfp w/ led & 2x gbe rj45, w/bmc, 60w adapter |
| nca-1515c | c3308, 2-core, 1x ddr4 ecc sodimm, 4x gbe rj45 w/o bypass, 36w adapter |
| nca-1515d | c3558, 4-core, 2x ddr4 ecc sodimm, 4x gbe rj45 w/ 1 pair of gen3 bypass & 2x gbe sfp w/ led, w/ bmc, 60w adapter |
| nca-1515e | c3858, 12-core, 2x ddr4 ecc sodimm, 4x gbe rj45 w/ 1 pair of gen3 bypass, 2x gbe sfp w/ led & 2x gbe rj45, w/bmc, 60w adapter |
| nca-1515f (by project) | c3958, 16-core, 2x ddr4 ecc sodimm, 4x gbe rj45 w/ 1 pair of gen3 bypass, 2x gbe sfp w/ led & 2x gbe rj45, w/bmc, 60w adapter |
all product specifications are subject to change without prior notice
