特点&外观
- 采用intel® d-2100 (8/12/16)
- max. 512gb
- 8x gbe rj45 & 4x sfp
new
intel xeon®d-2100 8~16核处理器(代号skylake-d)
- intel®xeon d-2100 8/12/16核心处理器
- 4x ddr4 2666 mhz，最大512gb
- 8x gbe rj45 and 4x sfp
- 1个rj45 console, 1个板载网卡用于ipmi(可选)，2个usb2.0
- 2个2.5英寸hdd/ssd内置插槽，1x m.2板载插槽
- intel® quickassist technology (by sku)
产品概述
nca-4025具有8、12或16核intel®xeon®d-2100处理器、8x gbe rj45、4x sfp ，支持intel®quickassist technology(由sku)，在sd-wan中运行多个虚拟网络功能vnfs时，具有显著的性能提升；可减少测试和验证工作，并加快投放市场的时间。
硬件规格
| platform | |
| form factor | 1u 19” rackmount |
| processor options | intel® xeon® d2100 8/12/16 cores |
| cpu socket | 1 x onboard |
| chipset | n/a |
| security acceleration | intel® quickassist technology (by sku) |
| bios | ami spi flash bios |
| system memory | |
| technology | ddr4 2666mhz reg dimm |
| max. capacity | 512gb |
| socket | 4 x 288-pin dimm |
| networking | |
| ethernet ports | 8 x gbe rj45 intel® i350-am4 4 x sfp intel® soc integrated mac |
| bypass | - |
| nic module slot | 2 |
| lom | |
| io interface | 1 x lom for ipmi (optional) |
| opma slot | n/a |
| i/o interface | |
| reset button | 1 (default: software reset control by gpio) |
| led | power/status/storage |
| power button | 1 x atx power switch |
| console | 1 x rj45 |
| usb | 2 x usb 2.0 |
| lcd module | n/a |
| display | n/a |
| power input | ac power inlet on psu |
| storage | |
| hdd/ssd support | 2 x 2.5” internal |
| onboard slots | 1 x m.2 2242 |
| expansion | |
| pcie | n/a |
| mini-pcie | n/a |
| sim card slot | n/a |
| miscellaneous | |
| watchdog | yes |
| internal rtc with li battery | yes |
| tpm | yes (optional) |
| cooling | |
| processor | passive cpu heatsink |
| system | 4 x swappable smart fans |
| environmental parameters | |
| temperature | 0~40ºc operating -20~70ºc non-operating |
| humidity (rh) | 5~90% operating 5~95% non-operating |
| system dimensions | |
| (wxdxh) | 438 x 510 x 44 mm |
| weight | 8.6 kg |
| package dimensions | |
| (wxdxh) | 739 x 582 x 215 mm |
| weight | 15 kg |
| power | |
| type / watts | 450w 1 1 redundant psu |
| input | ac 110~240v @47~63 hz |
| certification | |
| approvals and compliance | rohs, ce/fcc class a, ul |
订购信息
| nca-4025a | intel skylake 16c d-2187nt w/ qat, 8x gbe rj45, 4x sfp |
| nca-4025b | intel skylake 16c d-2183it w/o qat, 8x gbe rj45, 4x sfp |
| nca-4025c | intel skylake 12c d-2166nt w/ qat, 8x gbe rj45, 4x sfp |
| nca-4025d | intel skylake 12c d-2163it w/o qat, 8x gbe rj45, 4x sfp |
| nca-4025e | intel skylake 8c d-2145nt w/ qat, 8x gbe rj45, 4x sfp |
skylake d
