特点&外观
- intel atom denverton
- wide temp.-40~70ºc
- 4x rj45, 2x sfp
new
宽温网络设备intel®atom®c3000 (denverton)
- intel® atom® 2~8 cores c3308/c3508/c3708 cpu (denverton)
- 4x rj45, 2x sfp or 2x rj45 (by sku), 1 pair of gen3 bypass
- wide operating temperature range: -40~70ºc (sku c to 60ºc)
- sku a/d:1x 260-pin sodimm, sku b/c/e/f:2x 260-pin sodimm
- 1x m.2 b key 3042 for lte, 2242 ssd (signal: usb3.0, sata) with nano-sim
- 2x mini-pcie for wi-fi,lte (signal: usb2.0,pcie) with nano-sim
- sku d/e/f: 1x optional removable m.2 lte caddy
- intel® quickassist technology up to 10gbps
- 1x mini usb console, 2x usb 3.0 (sku b/c), 1x 2.5” hdd/ssd bay (optional)
- optional rack mounting kit support
产品概述
ncr-1510是一款宽温无风扇网络设备，为sd-wan或ucpe优化。该平台支持在苛刻的环境和关键基础设施中部署sd-wan服务。ncr-1510由英特尔®atom®c3000(代号denverton) cpu驱动，具有稳定的性能和英特尔的quickassist技术，运行速度可达10gbps，在紧凑的外形中提供加密加速和工业级局域网功能。是企业应用于sd-wan、ucpe或边缘安全网关的最佳无风扇桌面网络设备。
产品规格
| platform | |
| cpu | intel® atom® c3308/c3508/c3708 (denverton) |
| chipset | soc |
| bios | ami spi flash bios |
| memory technology | ddr4 up to 2400mhz ecc/non-ecc dimm |
| memory capacity | sku a/d:1x 260-pin sodimm, sku b/c/e/f:2x 260-pin sodimm |
| memory socket | sku a/d: 32gb, sku b/c/e/f:64gb |
| storage | |
| sata storage | hdd/ssd support 1 x 2.5” bay (optional) |
| i/o | |
| default lan | 4 x gbe rj45 intel® soc integrated mac 2 x sfp intel® i210 (by sku) or 2 x gbe rj45 intel i210 |
| bypass | 1 pair of gen3 |
| console | 1 x mini usb |
| security acceleration | intel® quickassist technology |
| usb 3.0 | 2 x type a |
| tpm | onboard tpm 2.0 |
| power and mechanical | |
| power input | 1 x 2-pin terminal block |
| type/watt | 12v, 5a |
| expansion | 1x m.2 b key 3042 for lte, 2242 ssd with nano-sim; 2x mini-pcie for wi-fi,lte with nano-sim |
| reset | 1x reset button |
| processor cooling | passive cpu heatsink |
| system cooling | fanless |
| os and certifications | |
| certifications | rohs, ce/fcc class a |
| physical and environmental | |
| storage temperature | -20°c to 85°c |
| operating temperature | -40°c to 70°c |
| operating humidity | 5% to 95% (non-condensing) |
| dimensions (w x h x d) | 310 mm x 44 mm x 240 mm (12.20" x 1.73" x 9.45") |
| weight | 3 kg (6.6 lbs) |
| watchdog | yes |
| internal rtc | yes |
订购信息
| ncr-1510a | c3308, 6x gbe rj45 w/ 1 pair of gen3 bypass |
| ncr-1510b | c3508, 6x gbe rj45, w/ 1 pair of gen3 bypass |
| ncr-1510c | c3708, 4x gbe rj45, 2x gbe sfp, w/ 1 pair of gen3 bypass |
| ncr-1510d | c3308, 6x gbe rj45 w/ 1 pair of gen3 bypass, 1x optional removable m.2 lte caddy |
| ncr-1510e | c3508, 6x gbe rj45, w/ 1 pair of gen3 bypass, 1x optional removable m.2 lte caddy |
| ncr-1510f | c3708, 4x gbe rj45, 2x gbe sfp, w/ 1 pair of gen3 bypass, 1x optional removable m.2 lte caddy |
| 4g lte radio modem with lte cat-6 embedded module | |
| 4g lte-advanced pro radio modem with lte cat-12 embedded module |
all product specifications are subject to change without prior notice
