精确、效能、创新 nca-4020 next-gen vcpe/ucpe platform for accelerated sd-wan
特点
- intel® xeon d-2100 4~16 cores processor (skylake-de)
- 4x 288pin ddr4 2666 mhz reg dimm, max. 128gb
- 10x gbe rj45 (4/8 port poe ), 4x 10g sfp
- 1x rj45 console, 2x usb 2.0, 1x vga (intenal pin header)
- 2x 2.5” internal hdd/ssd bays, 1x m.2-2280/22110, b key
- intel® quickassist technology (by sku)
- 1x pci-e*8 fh/hl (optional), 3x nano sim
- 3x hot-swappable cooling fans, 600w 1 1 redundant psu
概述
the nca-4020, a rackmount network appliance powered by intel® xeon® d-2100 (codenamed skylake-de) cpu, features 4~16-core computing performance, 10x gbe rj45 (4 or 8 port poe ), 4x 10g sfp and intel® qat for improved network performance; it is also a verified intel® selection solution for ucpe.
外观
| cpu |
intel® xeon® d2100 4~16 cores |
| chipset |
n/a |
| bios |
ami spi flash bios |
| memory technology |
ddr4 2666mhz reg dimm |
| memory capacity |
128gb |
| memory socket |
4x 288-pin dimm |
|
| sata storage |
2x 2.5" internal hdd/ssd bays, 1x m.2-2280/22110, b key |
|
| default lan |
10x gbe rj45 (4/8 port poe by sku), 4x 10g sfp |
| console |
1x rj45 |
| display output |
internal pin header |
| usb 2.0 |
2 x type a |
| tpm |
yes (optional) |
|
| power input |
ac power inlet on psu |
| type/watt |
600w 1 1 redundant psu |
| expansion |
1x pci-e*8 fh/hl (optional), 1x mini-pcie, 3x nano sim |
| reset |
1x reset button |
| processor cooling |
passive cpu heatsink |
| system cooling |
3x individual hot-swappable cooling fans with smart fan |
| certifications |
rohs, ce/fcc class a, ul |
| storage temperature |
-20°c to 70°c |
| operating temperature |
0°c to 40°c |
| operating humidity |
5% to 90% (non-condensing) |
| dimensions (w x h x d) |
438 mm x 44 mm x 500 mm (17.24" x 1.73" x 19.69") |
| weight |
7.9 kg (17.38 lbs) |
| lcd module |
n/a |
| watchdog |
yes |
| internal rtc |
yes |
| nca-4020a |
skylake-d-2187, 10x gbe rj45 (w/8x port poe ) 4x sfp , bmc |
| nca-4020b |
skylake-d-2166, 10x gbe rj45 (w/8x port poe ) 4x sfp , bmc |
| nca-4020c |
skylake-d-2146, 10x gbe rj45 (w/4x port poe ) 4x sfp , bmc |
| nca-4020d |
skylake-d-2145, 10x gbe rj45 (w/4x port poe ) 4x sfp , bmc |
